Features
Sealing Features:
- Seal Lengths: 20″, 25″, 30″
- Seal Width: 5/16″
- Single side impulse heater bar with opposing pressure bar (top jaw heated)
- Pneumatically operated sealing jaw for high pressure sealing
- Independent digital seal and cool timers
- Digital sealing pressure switch with adjustable band to set high and low tolerances
- Seal Only switch to disable vacuum and retract the nozzle for use as an impulse sealer
Temperature Control Features:
- Temperature controller with digital readout to 350° F (high temp optional)
- Adjustable temperature band for high and low alarm tolerances
- Seal time begins when set temperature is achieved to prevent inconsistencies with heat build up in sealing jaws, ensuring repeatable seals
Vacuum Gas Flush Features:
- Type 60 Venturi Vacuum pump for fast evacuation of air
- Single Vacuum/Gas Flush Nozzle (snorkel) to accommodate narrow or wide bags
- Digital timers for each stage of vacuum and gas flush (when applicable), up to 10 seconds
MedPAC Medical Control Features:
- ISO 11607 Compliant
- Fully calibratable pressure switch and temperature controller
- External ports in control cabinet for verification and calibration of internal controllers
- Real time seal process parameter monitoring (Temperature, Pressure, Time)
- Alarm function prevents operation when there is a deviation from validated settings
Safety Features:
- Pneumatic low-pressure jaw close with release if obstruction is detected
- Jaw close time out with release when delay is detected
- Heavy duty seal transformer(s) with thermal overload protection
Versatility:
- Ported Exhaust for plumbing exhaust outside of a cleanroom
- Stainless Steel Construction to mitigate particle contamination
- Designed to effectively package medical devices in a wide variety of bag materials
Specs:
- Air Requirement (min): 100 psi
- Electrical Requirement: 115v standard (230v optional)
- Dimensions: 23″ – 33″ W x 8″ H x 15″ D
- 2 year limited warranty
- Made in USA
