Features
Sealing Features:
- Seal Lengths: 30”, 36”, 42”, or 48”
- Seal Width: 5/16”
- Bi-Active Sealing Jaws (Both Jaws Heated)
- Jaw selector switch to allow for single top heat only, bottom heat only, or both jaws heated
- Independent digital seal and cool timers (1.0 – 9.9 seconds)
- Digital sealing pressure switch with adjustable band to set high and low tolerances
- Seal Only switch to disable vacuum and retract the nozzle for use as an impulse sealer
- Adjustable sealing head angle for vertical or horizontal use
Temperature Control Features:
- Temperature controller with digital readout to 350° F
- Adjustable temperature band for high and low alarm tolerances
- Seal time begins when set temperature is achieved to ensure repeatable seals with high production use
Vacuum Gas Flush Features:
- 3/4 Hp Vacuum pump for fast evacuation of air
- Dual, large stainless steel vacuum nozzles
- Digital timers for each stage of vacuum and gas flush (up to 15s vac, 3.75s gas)
MedPAC Medical Control Features:
- ISO 11607 Compliant
- Fully calibratable pressure switch and temperature controller
- External ports in control cabinet for verification and calibration of internal controllers
- Real-time seal process parameter monitoring (Temperature, Pressure, Time)
- Alarm function prevents operation when there is a deviation from validated settings
Safety Features:
- Pneumatic low-pressure jaw close with release if obstruction is detected
- Jaw close time-out with release when delay is detected
- Emergency stop button
- Locking control box cover to prevent unauthorized access to adjust settings
Versatility:
- Ported Exhaust for plumbing exhaust outside of a cleanroom
- Open head design for easy access and bag positioning
- Designed to effectively package medical devices in a wide variety of bag materials
Specs:
- Foot switch cycle activation
- Air Requirement (min): 100 psi
- Electrical Requirement: 220 volt, single phase
- 3 year limited warranty
